LED Neon Strip- 20X20mm- bending side vertically -single color
Our LED Neon Strip is an excellent lighting product, which has the characteristics of soft and curved. Its size is 20x20mm, making it very suitable for installation in a compact space. This product can be bent vertically to make it more flexible and versatile.
In addition, our LED Neon Strip is a monochrome design, which provides a single color lighting effect. You can choose different colors as needed to create a charming lighting atmosphere.
|
Dimension |
W20* H 20mm |
|
LED Source |
SMD2835 |
|
LED Brand |
EPISTAR |
|
LED Qty |
120LEDs per meter |
|
LED BIN |
3SDCM |
|
Luminous Flux |
24-26Im per LED |
|
Input Voltage |
12VDC / 24VDC |
|
Power |
14.4 watts per meter |
|
Color Temperature |
Single Color / Dual Color / RGB / Magic RGB / DMX512 Single Color |
|
Cut Unit |
Every 2.5cm(12VDC) / Every 5cm(24VDC) |
|
Beam Angle |
120° |
|
CRI |
Ra80 / Ra90 |
|
PCB Width & Diffuser |
10mm width, silicone diffuser |
|
Operating Temperature |
-20℃ to 50℃ |
|
IP Rating |
IP67 |
|
Bending Direction |
Up & Down bending |
|
Warranty |
3 years |
|
Max. Run Length |
5 meters per roll as standard |
|
Certifications |
ISO9001, ETL, CE, RoHS |
Product Features
A Variety Of Wire Entry Methods
Suitable For Different Installation Sites
Customized Service
Always Meet Your Demand
Certificates
Project Cases
FAQ
2. Using double side thermal conductive tape to attach the LED strip to the aluminum profile for better heat dissipation.
3. Ensure air circulation in the installation area, as air circulation helps dissipate heat from the LED strip.
4. Ensure that the ambient temperature is not too high. The maximum ambient temperature should not typically exceed 50 degrees.
