LED Neon Strip- 20X20mm- bending direction vertically -single color

Our LED Neon Strip not only has excellent performance and durability, but also has the advantages of long life and low energy consumption. It uses advanced LED technology to provide uniform brightness and efficient lighting effects. Whether it is business or home, you can associate your choice of our LED Neon Strip to bring a high -quality lighting experience to your space.

Inquiry

Write a Review

Dimension	W20* H 20mm
LED Source	SMD2835
LED Brand	EPISTAR
LED Qty	120LEDs per meter
LED BIN	3SDCM
Luminous Flux	24-26Im per LED
Input Voltage	12VDC / 24VDC
Power	14.4 watts per meter
Color Temperature	Single Color / Dual Color / RGB / Magic RGB / DMX512 Single Color
Cut Unit	Every 2.5cm(12VDC) / Every 5cm(24VDC)
Beam Angle	120°
CRI	Ra80 / Ra90
PCB Width & Diffuser	10mm width, silicone diffuser
Operating Temperature	-20℃ to 50℃
IP Rating	IP67
Bending Direction	Up & Down bending
Warranty	3 years
Max. Run Length	5 meters per roll as standard
Certifications	ISO9001, ETL, CE, RoHS

Product Features

Focus on Light Efficiency Uniform Lighting

High transmittance 15-20% higher than the industry

55℃ - 40℃ EXTREME ENVIRON MENTS CAN ALSO BE USED

100% DOW-CORNING SILICONE FOOD-GRADE SILICONE

A Variety Of Wire Entry Methods

Suitable For Different Installation Sites

5 (4)

6 (3)

7 (4)

Customized Service

Always Meet Your Demand

LED Neon Strip- 20X20mm- bending direction vertically -single color 9

5 years warranty

LED Neon Strip- 20X20mm- bending direction vertically -single color 10

No MOQ

LED Neon Strip- 20X20mm- bending direction vertically -single color 11

Customized

LED Neon Strip- 20X20mm- bending direction vertically -single color 12

Free Sample

LED Neon Strip- 20X20mm- bending direction vertically -single color 13

3 Min.quote

LED Neon Strip- 20X20mm- bending direction vertically -single color 14

Shipping in 24h

LED Neon Strip- 20X20mm- bending direction vertically -single color 15

Free design service

LED Neon Strip- 20X20mm- bending direction vertically -single color 16

Learn more about services

Certificates

zhengshu1

zhengshu2

zhengshu3

zhengshu4

zhengshu5

zhengshu6

zhengshu7

zhengshu8

Project Cases

1 (7)

2 (3)

FAQ

ARE YOU A MANUFACTURER?

Yes,We are.Welcome ODM request.

WHY U? AS THERE ARE MANY SUPPLIER OF LED STRIP

Good question and had to answer.We have all color wave covering on the led strip and also max 220lm/W high efficiency for the Linear . I just know all the request from our clients can be achieved into action with our RD department.Many famous than us,but we are most flexible supplier like our products.

WHAT ABOUT THE LEAD TIME FOR MASS PRODUCTION?

3days fro sample and 7days for the IP20 strip production.10days for the logo printing on pcba and 12 or 15days for the waterproof led strip.Please click below to chat to get more.
